# D3 Scale Area Chart With Axis

Note:

The area generator produces an area, as in an area chart. An area is defined by two bounding lines, either splines or polylines. Typically, the two lines share the same x-values (x0 = x1), differing only in y-value (y0 and y1); most commonly, y0 is defined as a constant representing zero. The first line (the topline) is defined by x1 and y1 and is rendered first; the second line (the baseline) is defined by x0 and y0 and is rendered second, with the points in reverse order.

Key Code:

``````
var area = d3.area()
.x1(function(d){return xScale(d[0]);})
.y1(function(d){return yScale(d[1]);})//draw the top line. Similar idea with line chart
.x0(function(d){return xScale(d[0]);})
.y0(yScale(0));//draw the base line. Note: the x0 cannot be 0. it should be a line (x0,y0) --> (xScale(d[0]),0)  --> x axis
``````
``````
var margin = {top: 20, right: 20, bottom: 50, left: 70};
var width = 500 - margin.left - margin.right;
var height = 200 - margin.top - margin.bottom;

//this is svg is actually group
var svg = d3.select("#diagram").append("svg")
.attr("width",width+margin.left+margin.right)
.attr("height",height+margin.top+margin.bottom)
.append("g")  //add group to leave margin for axis
.attr("transform","translate("+margin.left+","+margin.top+")");

//the code above should be same

var dataset = [[5, 20], [480, 90], [250, 50], [100, 33], [330, 95],
[410, 12], [475, 44], [25, 67], [85, 21], [220, 88]];
//for each d, d[0] is the first num, d[1] is the second num
//set y scale
var yScale = d3.scaleLinear().rangeRound([0,height]).domain([d3.max(dataset,function(d){return d[1];}),d3.min(dataset,function(d){return d[1];})]);//show negative
var xScale = d3.scaleLinear().rangeRound([0,width]).domain(d3.extent(dataset, function(d){return d[0];}));//scaleBand is used for  bar chart

//sort x
dataset.sort(function(a,b){
if(a[0]< b[0]){
return -1;
}
else{
return 1;
}
})

var line = d3.line()
.x(function(d){return xScale(d[0]);})
.y(function(d){return yScale(d[1]);})
.curve(d3.curveBasis);//default is d3.curveLinear

//add line to svg. use path-- > to know svg path
//must add css class line, you can try to remove it and see the result
svg.append("path").data([dataset]).attr("class","line").attr("d",line);

var yAxis = d3.axisLeft(yScale);
svg.append("g").call(yAxis);

var xAxis = d3.axisBottom(xScale);/*.tickFormat("");remove tick label*/
svg.append("g").call(xAxis).attr("transform", "translate(0,"+height+")");

//add label for x axis and y axis
svg.append("text").text("Y Label")
.attr("x",0-height/2)
.attr("y",0-margin.left)
.attr("dy","1em")
.style("text-anchor", "middle")
.attr("transform","rotate(-90)");
svg.append("text").text("X Label")
.attr("x",width/2)
.attr("y",height+margin.bottom)
.style("text-anchor", "middle");
``````

Tips:

Use basis may lose precision in the chart!

The basis interpolation is implementing a beta spline, which people like to use as an interpolation function precisely because it smooths out extreme peaks. This is useful when you are modeling something you expect to vary smoothly but only have sharp, infrequently sampled data. A consequence of this is that resulting line will not connect all data points, changing the appearance of extreme values.

Source:Stack Overflow
